Power Team C Series Hydraulic Cylinders

Designed for operating pressures up to 700 bar, these cylinders are available in single-acting, double-acting, and pull-type configurations and meet the requirements of ANSI B30.1. Capacities range from 2 to 1 220 tons (approximately 1.8 to 1 107 metric tonnes), with stroke lengths from 8 mm to 511 mm, supporting a wide variety of lifting and positioning applications. Selected Power Team cylinder series also feature standard swivel caps, helping to reduce side loading and improve operational safety and performance.

C Series cylinders feature threaded collars, base mounting holes, and piston rod ends, enabling quick, secure, and versatile mounting across a wide range of applications.

• Aluminium bronze bearing educes wear caused by off-centre loads.
• Maximum-sized return springs accelerate piston retraction and extend spring service life.
• Standard collar threads on all C-Series models simplify fixtures and setup.
• Removable rubber boots protect collar threads during transport and storage.
• Solid steel cylinder body delivers long-term durability in demanding applications.
• Chrome-plated piston rod resists wear and corrosion for extended service life.
• Wide range of accessories available, mounting directly to the piston rod, collar, or base.
• Base mounting holes standard on 5–55 ton cylinders; optional on 75 and 100 ton models.
• Standard 3/8 in. NPTF female half coupler for easy hydraulic connection.
• Complies with ANSI/ASME B30.1 safety standards or assured operational safety.
