SP Series H-Frame Shop Presses
Tonnage options: 55, 100, 150–200 tons
Heavy-duty pressing performance for workshop and industrial applications
SP Series H-frame shop presses are engineered for demanding pressing, straightening, and bending applications. Designed for strength, stability, and flexibility, these presses support full-capacity off-centre loading and offer generous working clearances to accommodate bulky workpieces. Multiple power and cylinder configurations are available to suit a wide range of operational requirements.
SP Series H-Frame Press – 55 Ton
Built for high-performance shop use, the 55-ton model delivers full-capacity pressing with excellent stability and safe, controlled operation.
Key features
- Full off-centre pressing at rated capacity across the upper frame width without buckling or bending
- Maximum daylight of 42 in. × 36 in. (1,067 mm × 914 mm) for easy positioning of bulky components
- Press bed height easily adjusted via winch
- Friction brake prevents bed drop and handle spin when released
- Power options for single-acting cylinder models:
- Two-speed hand pump
- Electric/hydraulic pump
- Air/hydraulic pump
- Double-acting cylinder models supplied with electric/hydraulic pump
- Optional remote control enables fingertip control of cylinder travel while viewing work from all sides
- Can be used horizontally for specialised applications with user-supplied support legs
SP Series H-Frame Press – 100 Ton
The 100-ton model is designed for larger pressing jobs, offering enhanced work-head mobility and increased daylight for oversized workpieces.
Key features
- Cylinder work-head glides across the upper frame on rollers and locks in place for off-centre pressing
- Press bed raised and lowered by a winch system that locks for secure pin insertion
- Upper bolster can be lowered 8 in. (203 mm) for faster setup on repetitive applications
- Generous daylight of 42 in. × 50 in. (1,067 mm × 1,270 mm) for large workpieces
- Upright spacing allows easy side entry for bars or shafts used in straightening and bending
- Available with single- or double-acting cylinder configurations
- Hydraulic pump options include:
- Two-speed hand pump with 2-gallon (7.6 L) reservoir
- PE172 electric/hydraulic pump
- PQ Series “Quiet” electric/hydraulic pump with low noise output
- Can be used horizontally for specialised pressing applications with user-supplied supports
SP Series H-Frame Presses – 150 to 200 Ton
Standing approximately 7.5 ft (2.3 m) tall, these heavy-duty presses are built to handle the largest industrial pressing tasks with precision and control.
Key features
- Designed for high-tonnage, large-scale pressing applications
- Wide horizontal work-head travel for improved positioning flexibility
- Heavy-duty frame withstands rated capacity loads across the full width of the press
- Winch mechanism provides easy press bed positioning and locks for retaining pin insertion
- Upper bolster can be lowered 11 in. (279 mm) for faster setup on repetitive jobs
- Upright spacing allows easy side entry for straightening or bending shafts and bars
- Fast cylinder approach powered by PQ1204S “Quiet” electric/hydraulic pump
- Remote control hand switch enables fingertip control of cylinder travel while viewing work from all sides
- an be used horizontally for specialised applications with user-supplied supports
