Power Team RGP Series Pancake Hydraulic Cylinders

Designed for operating pressures up to 700 bar, these cylinders are available in single-acting, double-acting, and pull-type configurations and meet the requirements of ANSI B30.1. Capacities range from 2 to 1 220 tons (approximately 1.8 to 1 107 metric tonnes), with stroke lengths from 8 mm to 511 mm, supporting a wide variety of lifting and positioning applications. Selected Power Team cylinder series also feature standard swivel caps, helping to reduce side loading and improve operational safety and performance.

RGP Series Pancake Locking Collar, Single-Acting Cylinders

Tonnage range: 67–565 tons

RGP Series pancake locking collar cylinders are engineered for high-tonnage lifting applications where secure load holding and minimal clearance are critical. The integrated mechanical locking collar safely supports loads for extended periods, eliminating the risk of hydraulic leak-down and unintended load movement.

Key features

• Mechanical locking collar provides positive load support for long-duration holds
• Patented 5° deep swivel cap concentrates load forces and minimises off-centre loading
• Compact, low-profile design ideal for confined or restricted work areas
• Buttress thread locking collar delivers exceptional strength, security, and fast run-down to save setup time
• Power-Tech® nitro-carburised surface treatment enhances corrosion resistance and long-term durability
• Integrated weep hole provides a visual indicator of piston over-travel
• High-flow 3/8 in. NPTF female half coupler and integrated carry eyelets included as standard
