Remote-Mounted Valve
Operating pressure: up to 700 bar (10,000 psi)
Maximum flow rate: 19 L/min (5 GPM)
Power Team remote-mounted valves are designed for high-pressure hydraulic systems requiring reliable control of single- and double-acting cylinders. Available in multiple configurations and actuation types, these valves support flexible system layouts and efficient remote operation.
Remote-Mounted Valves – 1/4 in. Ports
Max flow rate: 19 L/min (5 GPM)
Max pressure: 700 bar (10,000 psi)
3/4-Way / 2-Position Solenoid-Actuated Valves
- Application: Single- or double-acting cylinders
- Actuation: Solenoid-operated (models 9593, 9524 and 9554)
3/4-Way / 2-Position Air-Actuated Valves
- Application: Single- or double-acting cylinders
- Actuation: Air-operated (model 9595)
Remote-Mounted Valves – 3/8 in. Ports
Max flow rate: 19 L/min (5 GPM)
Max pressure: 700 bar (10,000 psi)
4-Way / 3-Position Manual Valves (Closed Centre or Tandem Centre) with POSI-CHECK®
- Application: Single- or double-acting cylinders
- For single-acting cylinders, one port must be plugged
- For double-acting cylinders, either port can be used for advance or return
- Actuation: Lever-operated with detent positioning
3-Way / 2-Position Solenoid Valve
- Application: Single-acting cylinders
- Actuation: Solenoid-operated (115/230/24 VAC, 50/60 Hz)
4-Way / 3-Position Tandem Centre Solenoid Valve with POSI-CHECK®
- Application: Double-acting cylinders
- Actuation: Solenoid-operated (115/230/24 VAC, 50/60 Hz)
