Power Team H-Frame Roll-Bed Presses

RB Series H-Frame Roll-Bed^® Presses

Tonnage range: 80–200 tons

High-capacity Roll-Bed^® design for faster loading and heavy-duty pressing

RB Series H-frame Roll-Bed^® presses deliver powerful performance for demanding industrial pressing applications. Featuring the original patented Roll-Bed^® system, the bed extends outward for fast, efficient loading and unloading using a crane or lifting device—supporting loads up to 3 000 lb (1 360 kg). Designed for flexibility and control, these presses are ideal for heavy jobs requiring precision alignment and safe handling.

Key features

• Patented Roll-Bed^® extends outward for easier loading and unloading
• Roll-bed supports loads up to 3 000 lb (1 360 kg)
• Movable work-head glides side-to-side, providing full off-centre load capability across the upper frame
  • 80–100 ton models: 50.5 in. × 60 in. (1 283 mm × 1 524 mm)
  • 50–200 ton models: 51.25 in. × 64 in. (1 302 mm × 1 626 mm)
• Large working clearance (“daylight”):
• Double-acting cylinder with 13.125 in. stroke (333 mm) for high-force applications
• Fast cylinder approach powered by PQ1204S “Quiet” electric/hydraulic pump with remote hand control
• Adjustable lower bed width supports secure balancing and centring of heavy loads
• Upper bolster height adjusted via crank handle (optional drill motor upgrade for faster adjustment)
• Four locking pins secure the bolster during pressing operations
