Designed for operating pressures up to 700 bar, these cylinders are available in single-acting, double-acting, and pull-type configurations and meet the requirements of ANSI B30.1. Capacities range from 2 to 1 220 tons (approximately 1.8 to 1 107 metric tonnes), with stroke lengths from 8 mm to 511 mm, supporting a wide variety of lifting and positioning applications. Selected Power Team cylinder series also feature standard swivel caps, helping to reduce side loading and improve operational safety and performance.
RLS Series Low-Profile, Single-Acting, Spring Return Cylinders
Tonnage range: 5–150 tons
Ideal for low-clearance or space-constrained applications requiring high force
RLS Series cylinders are purpose-built for high-force lifting in applications where clearance is limited. With an ultra-low profile and rugged construction, these single-acting, spring-return cylinders deliver reliable performance in confined spaces without compromising safety or durability.
Key features
- Ultra-low starting height from 41 mm to 102 mm (1.63–4.00 in.)
- Cylinder body, piston, and gland nut feature Power-Tech® treatment for corrosion and abrasion resistance
- Standard domed piston rod on 5–30 ton models and swivel cap on 50–150 ton models to minimise off-centre loading
- Heavy-duty return spring provides fast piston retraction on all models except RLS50
- Angled hydraulic coupler improves access and clearance in tight installations
- Complies with ANSI/ASME B30.1 safety standards
