Walz LS-100 Skid Steer Scale

ON-BOARD FORKLIFT SCALE

The WALZ hydraulic model On-Board Forklift Scale system is an ideal solution for those looking to track production data and freight loads. In-field installation provides consistent weights thanks to our integral weighing system behind our hydraulic forklift scales.

• Complete Kit
• Simple Installation
• Easy Operation
• Simple Operation
• Plug & Play Design
• Adjustable Mounting Bracket
• Printer Interface
• LED Display

• Real world typical accuracy of ~97% (when lifting more than 10% of the truck’s capacity)
• 100,000 Lb+ lifting capacity
• Weighs in both pounds or kilograms
• Configurable graduations: 1, 2, 5, 10, 20 or 50 lb/kg increments
• Easy-to-use 6 button operation, with one touch weight capture
• Water-resistant, corrosion proof and shock resistant stainless steel housing, IP65
• Display measures 6.75″ x 5.0″x 2.75″ without stand
• Industry best display for easy operation for a safe, clear view of the load data
• 5000 PSI sensor (IP67)
• 9/16″ STOR female thread, on sensor
• Overload Count function
• Security protected with passcode protected calibration
• Weight totalization feature
• Live feature that keeps the weight on the display
• Tare function
• Truck toggle feature, ability to track weight loads on two separate trucks at one time
• Display modes for current load or total truck weight
• Full range push button zero
• Simple installation: Approximately 1-2 hours
• Powered of the machine battery 7-24 VDC
• For machines with 36 VDC or 48 VDC power supply, we recommend a step down converter
• Calibration test weights should be greater or equal to 10% of the scale/machine capacity
• Walz 1-Year Manufacturers Warranty

• Machine specific fittings kit
• 3″ hydraulic hose
• 12 VDC ticket printer
