Sy-Klone Vortex® MAX Powered Engine Cleaner

Specifications:

• Operating Specifications
• Operating range: 0-900 CFM (0-25.48 m3/min)
• Operation temperature: -40 °F to +176 °F (-40 °C to +80 °C) continuous; +185 °F (+85 °C) short exposure
• Mounting: Vertical or horizontal (Mounting plates available separately)
• Filter change: Filter should be changed when the maximum level of restriction has been exceeded, not to exceed 1000 operating hours
• Maintenance: No routine maintenance or cleaning of the precleaner is required

Product Specifications:

• Construction: Glass-filled injection moulded polypropylene exterior, steel hardware, 12V and 24V DC motor with sealed housing and sealed ball bearings
• Mounting Orientation: Horizontal or vertical; mounting plates available separately. NOTE: When mounting vertically, it is recommended that rain cap end is up. If rain cap end is down, remove rain cap.
• Product dimensions and weight: Height x Width x Length; Weight
• With rain cap: 13.3" x 14.3" x 24.1" (337 mm x 364 mm x 611 mm); 17 lbs. (7.7 Kg)
• Without rain cap: 13.2" x 14.3" x 21.5" (336 mm x 364 mm x 546 mm); 15.5 lbs. (7.0 Kg)
• With heavy-debris screen: 14.5" x 14.5" x 26.2" (368 mm x 369 mm x 665 mm); 21.8 lbs. (9.8 Kg)
• Packaged dimensions and weight: Height x Weight x Length; Weight:
• With rain cap: 14.5” x 15.5” x 25.75” (368 mm x 394 mm x 654 mm); 20 lbs. (9.07 kg)
• With heavy-debris screen: 18" x 18" x 35.37" (457 mm x 457 mm x 898 mm); 27 lbs. (12.25 kg)

Power Specifications:

• Vortex Max(s) must be wired to power ON when machine is operating
• Power requirement: 10.5 amps constant at 12V; 8 amps constant at 24V
• Voltage max/min: +-10% from Nominal voltage (12 or 24 Volt)
• Suggested fusing: 15 A Blade Fuse @ 12 VDC; 10 A Blade Fuse @ 24 VDC
• Electric motor rating: IP68 (Good water resistance, however, do not run underwater)

How it Works: The Sy-Klone Effect

The separation and ejection of debris, and high-efficiency filtering, all of which precleans air, is The Sy-Klone Effect.

• Dirty air enters the precleaned housing through the inlet end
• The debris-laden air is directed into a rotation – a “Vortex” – pushing the debris to the outside walls through centrifugal force. The debris rotates towards the outlet end
• Debris is ejected through the ejection port, and the fine dust that remains passes through Sy-Klone’s self-cleaning filter
• After passing through the high-efficiency filter, clean air is passed downstream to the engine and engine air filter through the outlet end

Benefits and Features:

Maximize Clean Air Downstream to the Engine

• Proprietary powered precleaning technology, combined with high-efficiency filtration

High-Airflow System

• Up to 900 CFM (25.48 m3/min) from a single unit provides protective power of clean air for wide range of machines

Reduce Total Cost of Ownership, Improve Productivity

• Provide sustained, clean air flow regardless of the machine’s operating state, even in idle
• Minimize downtime and maintenance costs
• Reduce dirty air downstream, which can abrade engine components and damage exhaust and aftertreatment systems
• Extend life of primary engine filter and engine, meet maintenance intervals

Versatile Installation Options

• Available in 12V and 24V configurations
• Compact size and footprint with variable mounting configurations
• Less expensive and easier installation as compared to multiple unit smaller airflow systems
