SpxFlow Hydraulic Torque Wrenches

HIGH CYCLE HYDRAULIC TORQUE WRENCH

Up to 71 816 Nm @ 700 Bar (53 000 lb-ft @ 10 000 Psi)

The TWHC long-stroke mechanism imparts a 30° nut rotation per stroke while maintaining a tight and compact nose radius: this is a clear advantage over the short stroke and backup pawl mechanisms of light-alloy competitive models. Fewer parts and reduced torsion during operation result in reduced wear, maintenance, and associated costs.

ENHANCED USABILITY

• Compact nose radius allows the tool to fit in tighter, hard-to-reach spaces
• Low weight, high strength design
• Fast operation, long stroke and optimum flow
• Multi-direction high flow swivel manifold, with threaded couplers for maximum flow performance
• Tool-free square drive reversal and Reaction Arm positioning

DESIGNED WITH SAFETY IN MIND

• Fully enclosed drive mechanism for operator safety
• The swivel manifold internal relief valve prevents retract-side over-pressurisation
• Fine tooth pawl prevents tool ‘lock-on’

QUALITY MEANS LOWER LIFE-CYCLE COSTS

• Designed for a high-cycle life — up to 2–3 times longer than existing technology.
• Increased reliability: The simple drive assembly reduces downtime.
• Corrosion resistant material for use in harsh environments including offshore and subsea.
