The R-9720 is the industry’s most versatile and rugged remote mount condenser. Its unique design allows installation on a horizontal surface or mounted below a roof or floor panel simply by changing two hose connectors. Suitable for off-highway applications, commercial trucks, or specialty vehicles where a radiator-mount or rooftop condenser cannot be used.

  • Capacity: 39 000 BTU/hr (8.8 kW)
  • Condenser Coil: Copper tubing, aluminium fins and plated steel headers
  • Current Draw: 12.3 Amps @ 13.6 Vdc (includes 4 Amps for A/C clutch); 6.17 Amps @ 27.2 Vdc (includes 2 Amps for A/C clutch)
  • Fan: 10-inch (25.4 cm) diameter, 4 blade fan with single speed long life motor
  • 16.8 kg
Part No.: T37001521118
OE No.: R-9720-12P-LT
